9v DC Signal Relay DPDT Non-Latching Non-Polarized 8-Pin PCB Mount

$ 8.99

Availability:
UPC:
Model #:
SRC-9VDC-SH

Description

Product Features



  • 9vdc Double Pole Double Throw 2 Form C (DPDT) bifurcated-cross-bar contacts.
  • High sensitivity - Low Coil Power Consumption 0.2w
  • Maximum Current Load is 1 amp (1a)
  • 8pin PCB Through-Hole Mount - standard 5.1mm x 7.6mm pin spacing
  • Cross Reference Similiar Part Numbers: Fujitsu RY-9W-K / Omron G5V-2-H1-DC9 / Axicom V23105-A5006- A201

DataSheet: SRC-9VDC-SH

Pin Diagram:





Photos (5)
